Name: Ultrasound Color Doppler Sonoscape P20 with 2 probe
SKU: 12228
Price: 189999 SEK
Availability: InStock

Product Description

SPECS

P20 system enhances flexibility and intelligence to a new level. Stable as ever, P20 improves its signal transmission and reception processors which leads to higher sensitivity and more accurate echo detection. What’s more, P20 is equipped with a wide range of transducers which adopt innovative technologies and therefore promises a confident diagnostic experience. Consistent quality performance across applications.

Enhanced with advanced imaging architecture and probe technologies, the system enlarges diagnostic capacity and quality across a wide range of applications

μ-Scan
Adaptive Multi-beam Imaging
Dynamic Color
Single Crystal Transducer

Ergonomic Design

21,5” LED monitor with articulated arm
13,3” Adjustable touch screen
Rotatable and height adjustable control panel

Available with a range of high definition probes:

Linear Array L741 (Vascular, Small parts, MSK etc.), 4-16 MHz/ 46 mm
Linear Array L742(Vascular, Small parts, MSK etc.), 4-16 MHz/ 38 mm
Linear Array L752(Vascular, Small parts, MSK etc.), 4-16 MHz/ 52 mm
Linear Array 12L-A(Vascular, Small parts, MSK etc.), 3-17 MHz/ 52 mm
Linear Array 12L-B(Vascular, Small parts, MSK etc.), 3-17 MHz/ 38 mm
Convex Array 3C-A (Abdominal, Obstetrics, Gynecology), 1.0-7.0 MHz/ R50 mm
Convex Array C1-6 (Single crystal) (Abdominal, Obstetrics, Gynecology), 1.0-8.0 MHz/ R50 mm
Convex Array C613(Cardiology, Pediatrics), 3-15 MHz/ R14mm
Phased Array 3P-A (Cardiac, Transcranial), 1.0-5.4 MHz
Phased Array 7P-B (Cardiac, Transcranial, Infant), 2-9MHz
Phased array S1-5 (Single crystal) (Cardiac, Transcranial), 1.0-7.0 MHz
Endocavity 6V3 (Gynecology, Obstetrics, Urology), 3-15 MHz/ R10 mm
Endocavity 6V1 (Gynecology, Obstetrics, Urology), 3-15 MHz/ R11 mm
Endocavity 6V3A (Gynecology, Obstetrics), 3-15 MHz/ R8 mm
Endocavity 6V7 (Gynecology, Obstetrics), 3-15 MHz/ R10 mm
Volumetric Convex Array VC6-2(Obstetrics, Abdominal, Gynecology), 2-6.8 MHz/ R40 mm
Volumetric Endocavity VE9-5 (Obstetrics, Gynecology, Urology), 2-13 MHz/ R10 mm
Biplane BCL10-5 (Urology), Convex 3.9-11 MHz/ R10mm, Linear 6-15 MHz/ 60mm
Phased Array Transesophageal MPTEE (Cardiac), 4-13 MHz
Linear Array 10I2 (Intra-operative), 4-16 MHz/ 25mm
Linear Array 12LI-A (Intra-operative), 4-16MHz/ 33mm
Linear Array 12LT-A (Intra-operative), 4-16MHz/ 33mm
Convex Array 6CT-A (Intra-operative), 3-15MHz/ R40mm
Convex Array 6CI-A (Intra-operative), 3-15MHz/ R40mm

P20 Standard Configurations:

P20 Main Unit size: 751×518×1350mm
21.5″ High Resolution LED Color Monitor
13.3″ High Resolution Touch Screen
Height Adjustable and Rotatable Operation Panel
Extended Keyboard
Five Transducer Connectors (Four Active + One Parking)
One Pencil Transducer Connector
Wifi Module
Hard Disk 500G

Optional configurations:

The Fifth Active Transducer Connector
ECG (Hardware / Cables: Must be Configured with ECG Software)
Built-in Battery
Built-in DVD

P20 Standard Configurations:

μ-Scan (2D Speckle Reduction Technology)
B (2B & 4B) Mode
Color Doppler Flow Imaging
Pulse Wave Doppler Imaging
HPRF
Continuous Wave Doppler Imaging
Power Doppler Imaging / Directional Power Doppler Imaging
M Mode
Tissue Harmonic Imaging
Tissue Specific Imaging
Simult Mode (Triplex)
Pulse Inversion Harmonic Imaging
Spatial Compound Imaging
LGC (Lateral Gain Compensation)
Full Screen Zoom
Image Rotation
Real-time 2D Panoramic Imaging
Biopsy Guide
PW Auto Calculation
Auto NT
Auto IMT
Auto EF
TEI Index
S-Guide
Auto Optimization (One Button Optimization for 2D / Color / PW)
DICOM 3.0: Store / C-Store / Worklist / MPPS / Print / SR / Q&R

Optional Configurations:

ECG (Configured with ECG Hardware and Cables)
Color M Mode
Anatomic M Mode
Tissues Doppler Imaging
Trapezoidal Imaging
Real-time Color Panoramic Imaging
VIS-Needle (Needle Visualization Enhancement)
Freehand 3D Imaging
Static 3D / 4D
Auto Face (Configured with 3D / 4D Module at the Same Time)
S-Live (S-Live / S-Live Silhouette)
S-Depth
AVC Follicle (Auto Volume Calculation)
Stress Echo
C-xlasto (Compression Elastography Imaging)
Contrast Imaging

Applicaitions:

Abdomen Package
Gynecology Package
Obstetrics Package
Cardiology Package
Small parts Package
Urology Package
Vascular Package
Pediatrics Package

Value without Compromise, Treat with Confidence

C-Xlasto Imaging

With C-xlasto Imaging, P20 enables comprehensive quantitative elastic analysis. Meanwhile, C-xlasto on P20 is supported by linear, convex and transvaginal probes, to ensure good reproducibility and highly consistent quantitative elastic results.

Contrast Imaging

Contrast Imaging with 8 TIC curves allows doctors to assess perfusion dynamics in a wide range of clinical settings, including both the location and evaluation of lesion parts.

S-Live

S-Live allows for detailed visualization of subtle anatomical features, thereby enabling intuitive diagnosis with real-time 3D images and enriching patient communication.

Pelvic Floor 4D Transperineal 4D pelvic floor ultrasound can provide useful clinical values in assessing the vaginal delivery impact on the female anterior compartment, judging whether the pelvic organs are prolapsed or not and the extent, determining if the pelvic muscles were torn accurately.

Anatomic M Mode

Anatomic M Mode helps you observe the myocardial motion at different phases by freely placing sample lines. It accurately measures the myocardial thickness and the heart size of even difficult patients and supports the myocardial function and LV wall-motion assessment.

Tissue Doppler Imaging

P20 is endowed with Tissue Doppler Imaging which provides velocities and other clinical information on myocardial functions, facilitating clinical doctors with the ability to analyze and compare the motions of different parts of the patient’s heart.
