Anesthesia machine AM852V

Specifications

Physical and Environmental Specification

Demension: L450xW405xH330mm

Weight: 22kg

Storage temperature: -22°c~+55°c

Working temperature: +10°c~+40°c

Storage humidity: ≤93°c

Vaporizer

Agent type: Enflurane, Halothane, Isoflurane

Flow range: 0.2~10L/min

Concentration: 0~5%

Work temperature: 15~30°c

Main unit

Mode: Semi-open, semi-closed, or closed system

APL valve: ≤6KPa

Gas supply: O2/N2O 0.28MPa~0.6MPa

Flowmeter: O2/N2O two tube flowmeter 0~10L/min

(with interlock protection devices ensuring the oxygen concentration ≥21%)

O2 flush: 25~75L/min

O2 deficiency: Audible alarm for at least 7 seconds alarm
